RM1A48D50 Solid State Relays

Name: RM1A48D50 Solid State Relays
Brand: SREE DHANAM AUTOMATION PVT. LTD.
Price: 750.0 INR
Availability: InStock

Price 750.0 INR/ Piece

Get a Price/Quote

MOQ : 10 Pieces

RM1A48D50 Solid State Relays Specification

Working Temperature
-20 deg to 70 deg C

Mechanical Life
Unlimited (No moving parts)

Coil Power
1W

Contact Material
Semiconductor

Contact Resistance
< 1 m

Coil Voltage
4-32V DC

Power Consumption
Approx. 1W

Dielectiric Strength
2500V AC, 1 min

Contact Form
SPST-NO

Ambient Temperature
-20 deg to 70 deg C Celsius (oC)

Protect Feature
Built-in Snubber Circuit

Product Type
Solid State Relays

Insulation Resistance
>1000 M @ 500V DC

Theory
Solid State Relay

Usage
Industrial Automation, Motor Control, Heaters, Lighting Circuits

Contact Load
50A @ 48-660V AC

Operate Time
<10 ms

Terminal Type
Screw Terminal

Rated Voltage
48-660V AC

Supply Terminal
Input: 4-32V DC

Size
Standard - Refer Manufacturer Datasheet

Color
Black/White

Dimension (L*W*H)
62 x 45 x 24 mm

Weight
Approx. 170g

RM1A48D50 Solid State Relays Trade Information

Minimum Order Quantity
10 Pieces

Delivery Time
1-7 Days

About RM1A48D50 Solid State Relays

carlogavazzi digital ssr switching relay
works in accordance with the phase angle control principle,
i.e., the output switching point in the AC sine wave depends
on the control input which can be either 4-20 mA or 0-10 VDC.
4 mA or 0 VDC correspond to zero output power whilst 20
mA or 10 VDC correspond to full output power (near linear
power response). The relay switches off every time the out-
put current crosses zero, and switches ON in accordance
with the applied control input.

CARLOGAVAZZI Soft starters we deals smps in pan india like chennai,coimbatore,bawana, bangalore ,mysore ,hyderabad ,nashik ,secunderabad,mumbai,delhi,noida,gurgaon,vasai, thane,ghaziabad ,faridabad,Haridwar,uttarkhand,dehradun,kolkata,uttarkhand

ahmedabad,rajkot,surat,indore,vapi etc

Efficient Switching for Industrial Automation

The RM1A48D50 Solid State Relay is tailored for efficient and noise-free switching in industrial automation setups. Its rapid response time (<10 ms) and robust construction make it an ideal choice for controlling motors, heaters, and lighting circuits, especially in environments subject to high shock and vibration.

Flexible Mounting and Safety Features

Designed for easy installation, this relay supports both panel mount and DIN rail mounting (with accessory). The included terminal cover ensures finger protection, while the LED indicator provides instant visual confirmation of input status, enhancing workplace safety and operational awareness.

FAQs of RM1A48D50 Solid State Relays:

Q: How is the RM1A48D50 relay installed in an industrial setting?

A: The RM1A48D50 can be panel mounted directly or DIN rail mounted using an accessory. Its screw terminals facilitate secure wiring, and the included terminal cover provides extra safety during installation.

Q: What are the benefits of using a solid state relay like the RM1A48D50 compared to mechanical relays?

A: Solid state relays, such as the RM1A48D50, offer silent operation, unlimited mechanical life due to the absence of moving parts, rapid response times, and improved durability under harsh conditions like shock, vibration, and humidity.

Q: When should a Triac or MOSFET output type be chosen for this relay?

A: A Triac output is ideal for AC loads, such as motors or lights, requiring zero-crossing switching, whereas a MOSFET output suits DC or low-voltage AC applications that demand precise switching performance.

Q: Where can the RM1A48D50 be used effectively?

A: This relay is widely used in industrial automation, motor control systems, heating equipment, and lighting circuits, especially in environments requiring high reliability and safety.

Q: What process should be followed to ensure safe usage of the RM1A48D50?

A: Ensure the relay is mounted securely, use the terminal cover for finger protection, maintain environmental conditions within specified limits (humidity, temperature), and verify correct input control voltage to prevent operational errors.

Q: How does the built-in snubber circuit benefit the RM1A48D50s performance?

A: The snubber circuit protects the relay from voltage spikes, enhances switching reliability, and prolongs relay life by minimizing electrical stress on the output semiconductor components.

Q: What indicates the RM1A48D50 relay is powered on or active?

A: An LED indicator on the relay illuminates when input control voltage is applied, providing a clear visual cue of power-on status for real-time monitoring.
